Specification | ||||
Category | Items | Content | ||
High frequency inverter power supply | Power:5.0kW Main inverter frequency: 40 kHz | |||
Perspective max rated capacity | Tube current 8 mA Tube voltage 120 kv | |||
Automatic fluoroscopy | tube voltage 40 kv~120kv,adjust automaticallytube current : 0.3mA~~4mA adjust automatically | |||
Manual fluoroscopy | tube voltage 40 kv~120kv, continuous tube current : 0.3mA~~4mA continuous | |||
Pulse fluoroscopy | tube voltage 40 kv~120kv, continuous tube current : 4.1mA~~8mA continuous | |||
Photography tube voltage, mA, mAs | 40~120KV, 20~100mA, 1~180mAs | |||
Plate holder size | 200mmx250mm(8”x10”) or 250mmx300mm(10”x12”) | |||
X-ray tube | X-ray tube special for high frequency | large focus:1.5, mall focus :0.3 Anode thermal capacity: 35kJ (47 kHu) Tube thermal capacity: 650kJ (867 kHu) | ||
Image intensifier | Imported 9 inch image intensifier | |||
CCD photography | Imported ultra-low illumination CCD radiography | |||
Monitor | Center definition is 1000 lines and frequency for picture refresh is 75Hz. | |||
CCU (central control) | HD progressive output, continuous adjustable recursion, many images storage, upright image, horizontal image, positive & negative image, image patching, LIH(last image freeze), OSD (monitor display). | |||
Structure and performance | Direction wheel and main wheel | Direction wheel can rotate in any direction, and main wheel can rotate in ±90°. | ||
C-arm | The up and down electrical stroke of pillar is 400mm. Monitor rotating angles ≥300° Forward and backward movement:200mm; Revolution around horizontal axis : ±180°; Revolution around vertical axis: ±15°, distance from focus to screen: 960 mm; C-arm open distance: 760mm C-arm arc depth: 640mm; Slipping on orbit : 120°(+90°~-30°) | |||
Configurations | ||
New integrated C-arm mainframe | one set | |
one set Combined high-frequency high-voltage X-ray generator and high-frequency power supply (5.0kW, 40 kHz, 120kV) | one set | |
imported 9 inch image intensifier | one set | |
Imported ultra-low illumination CCD radiography | one set | |
High-definition progressive output CCU control system | one set | |
High-definition progressive output CCU control system | one set | |
Imported dense grain grids | one set | |
Electrical adjustable beam limiting device | one set | |
14-inch high-definition medical dedicated monitor | one set | |
Unique hand-held controller | one set | |
