BS-112C Digital Remote Control Fluoroscopy X Ray Machine With High Performance and Moving Frequency C-arm System 5KW

Fluoroscopic Capacity
Max rated capacity : Tube Current 4mA, Tube Voltage 120kV
Automatic Fluoroscopy: Tube Voltage:40kV~120kV Adjust Automatically
Tube Current : 0.3mA~4mA set manually
Manual Fluoroscopy: Continuous Tube Voltage:40kV~120kV
Continuous Tube Current : 0.3mA~4mA
Pulse Fluoroscopy: Continuous Tube Voltage 40kV~120kV
Continuous Tube Current 4.1mA~30mA

Pulse frequency: 0.1~25fps, Continuously Adjustable

Photography Capacity
Max rated capacity: 5 KW
Tube Voltage and Current Combination :

40kV~49kV 1 ~180 mAs
50kV~59kV 1 ~140 mAs
60kV~69kV 1 ~125 mAs
70kV~79kV 1 ~110 mAs
80kV~89kV 1 ~100 mAs
90kV~99kV 1 ~80 mAs
100kV~109kV 1 ~63 mAs

110kV~120kV 1 ~50 mAs

Plateholder Size: 200mm*250mm or 250mm*300mm

X-ray Tube
X-ray Tube Special for High Frequency

Fixed anode Dual-focus : small focus: 0.3(Sole Advantage), Large focus:1.5mm

Inverter Frequency: 40KHz

Thermal capacity: 35KJ (47KHU)

VideoSystem
Image Intensifier: Image Intensifier made by TOSHIBA
CCD Video camera : 1.0 mega pixels ultra low-light CCD camera imported from Japan.

Monitor : High-definition, high-resolution, optional specification

Image Processing System

(standard) : real-time image collection, specular image , recursive level 0-15 continuously adjustable,last frame frozen, Gamma correction, mass storage,imageW/L adjustable, gray-scale conversion,interest district balance, reversal, noise reduction,intensify, smooth, sharpen, compress, enlarge,measurement, label, print and typesetting, DicomSCP, DicomSCU, DicomDIR, Dicom Printing,HIS

Structure
Directive wheel: ±90°revolution,can freely change the moving direction of the unit.
Ascending & Descending Range of Pillar : ≥400mm
C-arm: Forward and Backward Movement: 200mm
Revolution around Horizontal Axis: ±180°
Revolution around Vertical Axis : ±15° ( Advantage), better than others' ±12.5°, easier to take special positions radiography )
Focus screen distance:1000mm

C-arm opening :800mm,
C-arm arc depth : 640mm
Slip on orbit : 120°(+90°~-30°)

Features

1. Leading domestic level Mobile Surgical X-ray machine. Real continuously pulse fluoroscopy 25fps. Convenient connection with the Digital subtraction system.
2. One million pixels CCD camera makes the image more distinct.
3. World-class image processing technology software makes the image more distinct to make it more convenient for the doctors in the operation and diagnostic process. Standard DICOM interface makes it convenient to connect with the hospital information system.
4. The pulse fluoroscopy can obtain high –definition image from low dose to meet the requirement of the high-precision and high difficulty microinvasive operation
5. Low radiation dose used can protect the doctor and patient.
6. Unique double foot brake controller design makes it convenient to control the instrument inside and outside the operation room. This design can also protect the health care
professionals by reducing the opportunity to come into contact with the radiation.
7. Exclusive inside and outside monitor design makes it more convenient to observe the operation process either inside or outside the operation room. At the same time, this design
can facilitate the outdoor teaching and the real-time observation of the surgical procedures.
8. Uniquely designed basement electric auxiliary supporting arm, ensuring safer use.
9. Specially designed portable controller, facilitating operation.
10.New-pattern frame design with a small and pleasing shape.
11.High-quality combined HF-HV X-ray generator, greatly reducing the X-ray irradiation.
12.The fluoroscopic KV and MA automatic tracking function makes the image brightness and definition shift to the best condition automatically.
13.Toshiba image intensifier is employed, stable and reliable in quality and sound in image definition.
14.Dense X-ray grid is used, further improving the image definition.

Usage
Orthopaedics:osteopathy, diaplasis, nailing
Surgery: removing foreign body, cardiac catheter, implanting pace maker, interventional
therapy, partial radiography, local photography, and other work.

Configuration

1. New (with electric auxiliary support arm) C-arm host one set
2. High-frequency high-voltage X-ray generator and high-frequency inverter power supply(5.0KW,40KHZ,120KV) one set
3. Toshiba 9-inch image intensifier one set
4. 1 million pixel ultra-low-light digital cameras one set
5. Digital image processing system (workstation) one set
6. South Korean imported grids one set
7. Electric adjustable limit beam splitter one set
8. 19-inch 17-inch HD LCD Monitor one set
9. 14-inch HD monitor private medical one set
10. Single use hand-held controller one set
11. New TV Trolley one set
