c arm fluoroscopy machine / electric C-arm / updated electronic C-arm/ electronic C-arm/ C-arm with high definition LCD monitor/ C-arm with HF&HV generator/ C-arm with 10.4LCD can be rotated 180/ C-arm with large free space 800mm in arc/ C-arm with original Korean liner slide rail / C-arm with Omron Relay / 5KW C-arm with Omron Relay / the popular C-arm for sale / C-arm X-ray machine in China/ c arm x-ray machine prices/ elctronic 50kw U-Arm/ Radiography X Ray Machine/ U-Arm x ray machine cost / C-arm X-ray Machine Manufacturers/Suppliers
1,14'' LCD high definition display
2,Large free space in arc: the space can reach 800mm
3.with ISO
4.France Trixell Image Intensifier
5.Italy IMD X ray tube
6.Grid is Korea JPI
HF generator | 110kV,3.5 KW ,40kHz |
Fluoroscopy mode | Fluoroscopy mode40~110kV 0.5~5mA (KV manual and automatic); Pulsd fluoroscopy 40~110kv 0,5-5mA Boost fluoroscopy 40~110kV 5~10mA; Photography 40~110kV 1~250mAs |
X ray tube | Dual-focus fixed anode:0.6mm/1.5mm
|
Image intensifier | Three fields of vision 9, 6, 4.5 French Thales Brand |
CCD camera | CCD camera, Japanese Watt Brand, 360° rotation |
Image system | Recursive Noise Reduction Frame freezing Multi frame image storage Image conversing and rotating Screen display with image comparison
|
Mechanical motion specifications | Verticaltravel:0-400mm Horizontaltravel:0~200mm Rotation about horizontal axis:±180° |
C-arm dimension | Distance of focal spot to image generator(SID):1000mm Depth in arm≥650mm Mobile stand :1800mm*800mm*1850mm Image system: 750mm*530mm*1680mm |
Standard configuration | High resolution CCD camera:1set x-ray generator:1set 9” image intensifier:1set Digital Noise reduction system 14” High resolution monitor :2sets Mobile stand :1 set
|
* With HF & HV generator,inverter,and High quality image intensifier, the x ray generator can work stably.It also reduces the damage for the doctors caused by radiation. |
* 10.4"LCD friendly interface control board: easy operation and can be rotated to 180°(L90°,R90°) Compared with ordinary key board, our LCD display is not easy to be oxidized Besides, the trouble will be displayed in Chinese, which will improve the efficiency of fault diagnosis. |
* Pulse and boost fluoroscope provides all kinds of size of patients with clear diagnosis. |
* With a steering handle, it can adjust the direction quickly when moving.And parallel movement function is also available. |
* Equipped with unique block line wheels, it can avoid accident when the machine moves |
* Large free space in arc: the space can reach 800mm,which is convenient for operation. |
* 9"/6"/4.5" three fields of vision:it facilitates diagnosis of partial enlargement. |
* CCD camera with rotation function:range of camera rotation:360°. |
* Original Korean linear slide rail can make the the movement of the machine flexibly. |
* Applied with Omron Relay, the noise can be reduced and the life time of the equipment can be increased. |
Medical Equipment Co., Ltd. Nanjing Huadong Electronics Group is a filiale of HDE. With this strong backing, our company has had rapid development in the past years. The development in science and technology is our driving force. With the system innovation, we strive hard to develop medical equipment.
Our company covers 3,000 square meters and has 100 staff members. The engineers and technicians account for 40% of total employees. We follow the goal of "unity, innovation, strives for success, strive to be the first".
Our company manufactures two series of products:
Enzyme immunoassay products and washers are widely applied in such fields as clinical diagnosis, immunoassay study, microorganism antigen and antibody test, parasitic disease diagnoses, endocrine determination and plant disease-carrying insect study.
The other is used in X-ray image system of clinic and orthopedics clairvoyance. Through perfect designs and stable and reliable performance, our movable x-ray machines that are shaped in letter of C not only reduce the X-ray dosage doctors and patients receive, but also catch the clearest pictures.
These products sell well in Southeast Asia, Africa and the USA. Our company becomes a leader in the domain of medical equipment around the world.
The warranty and service
1.Warranty
We offer one year warranty and lifelong service.
2.Training
We provide customers free training in our factory.The accommodation charge should be borne by customers.
3.Extend Service
If you have any problem,we will response in 12hours by email,tel or fax.
We provide spare parts for ten years.
1.The standard exported woodencases.
2.Shipping during 15days,after receving your full payment.If urgent,then do ugent action!
1.What is the best price?
Reply: It depends on your final order quantity.
2.How long with the Warranty?
Reply: usully one year,if you want to extend,then we can. Meantime we can provide spare parts for ten years.
3.How about the quality?
Reply: we are the state-owned big group company, and since 1990. And we are the first C arm manufacturer in China.
Each year will adult.
4.What's the delievery time?
Reply: during 15days after receiving your full payment,if urgent,then can discuss.
5.What's the payment terms?
Reply: 100% T/T(If the quantity is big,can discuss)
6.How to assemble it?
Reply: we have assembled in our factory, when you received the C arm,just connect the computer line.
7.Whether you are existing or not?
Reply: you can know us on Internet,also can know us from your Chinese partner or friends, the most important, we will sign the contact, it is legal.
8.If you have more questions, welcome to contact!!
