50kw U-Arm Digital Radiography X Ray Machine
Two Configurations as following:
Scheme1: ORICH Generator, Toshiba Detector;
Scheme 2: CPI Generator, Toshiba Detector
Technology Parameter
| X-ray tube | Supplier: Toshiba Item no: E7843X |
1. High kV, small focus, meet all kinds of radiographic requirements and make film more excellent. 2.Ultra-long service life and very high reliability. |
||||
| Focus: 0.6/1.2mm | ||||||
| Max tube voltage: 150kV | ||||||
| Max tube current: 630mA | ||||||
| Power:20/46kW | ||||||
| Heat capacity: 150KHU | ||||||
| U-C arm | Stand height:2200mm |
1.UC arm support holds many independent movable joints,which can omnidirectionally rotate, ensures no dead angle. Control system of the whole motor frame and large adjustement of SID,which can satisfy accurately position demand. 2.Workmanlike UC arm as well as detector and X-ray tube equilibrium system, which can carry out radiography from erect, lying to sitting positon. 3.Infrared not -contact automatic collision avoidance system and double-speed electric adjustment mechanism, which ensure the operator and the patient safety. 4.Also can be remote controled. |
||||
| Arm up and down moving range: 1265mm | ||||||
| Distance from the center of the arm to the ground: ≥425mm | ||||||
| Arm rotating range: -30°-120° | ||||||
| Focus screen distance | Min: 1000mm | |||||
| Max: 1800mm | ||||||
| Tube moving range:800 mm | ||||||
| Flat panel Detector (Toshibai, Japan) | Vision: 17’’X17’’(43cm X43cm) |
1.Ultra-thin and high-resolution caesium iodide detector(thickness less than 70mm). 2.Adoption of supersensitive sensitizing module can catch image at low dose, which protect the health of patient and operator. 3.Modularization design apt to maintenance. 4.Multi-sensor imaging unit can display high-resolutioin image, even when display of computer is enlarged, details of image can also be displayed enough clearly. automatic repair and calibration technology of self equipped sensor has ensured healthy operation. |
||||
| Pixel matrix: 3008 X 3072 | ||||||
| Pixel size: 143µm | ||||||
| Gray-scale: 14 bit | ||||||
| spatial resolution: 3.5LP/mm | ||||||
| Imaging time: 5s | ||||||
| Weight: 17kg | ||||||
Main Features:
1. High voltage generator, APR auto radiography, instantaneous image can be caught easily;
2. With ultrathin and high resolution panel detector, clear image can be displayed;
3. Advanced and flexible UC-arm can rotate in full angle and move smoothly;
4. Intelligent digital image collection and treatment system and possesses excellent human-machine interface.
Certificates of Quality:
ORICH Medical Equipment(Tianjin) Co., Ltd is a Sino-US venture by and between Tianjin Pharmaceutical Holdings and US Full State Group. We specializ in R&D of Medical X-ray machines, our products include basix disgnostic x ray machine, high-frequency digital photography system, mobile x-ray machine, panaramic and digital dental, mammography x-ray equipment, etc.
Our obligation is to provide high-quality products for Hosipital and Clinics, this is for the health of doctors and patients around the world, so that everyone around the world would have a healthy checkup and treatment.
