Power Supply
|
Single phase AC three-wire system, voltage 180V ~ 250V;
Frequency 50Hz; source resistance ≤ 0.22Ω; Capacity 8kW; max current 37A ( instant ) |
|
|
Radiography |
Voltage: 50-90KV
|
|
|
|
Current: 16mA, 32mA, 63mA, 100mA
|
|
|
|
Time: 0.08-6.3s
|
|
|
X-ray tube focus
|
4.3 * 4.3 mm
|
|
|
Max. Photography scope
|
40cm * 40 cm ( when focus-skin distance is 1m )
|
|
|
Max. distance from focus of x-ray tube assembly to ground ( window downward ):
rotary column ≥ 177.5cm; Fixed column ≥ 172.5cm Min. distance from focus of x-ray tube assembly to ground ( window downward ): rotary column ≤ 53.5cm; Fixed column ≤ 48cm |
|
|
|
Width of tube assembly rotate around the axis of cantilever > 90°;
Width of tube assembly rotate forth around the axis of supporting stand: > 90° |
|
|
|
Dimensions of the complete unit moves ( L * W * H ):
a) 136cm * 69cm * 125cm ( for fixed column ) b) 136cm * 69cm * 134cm ( for rotary column ) |
|
|
|
Control distance of remote switch exposure: about 7m
|
|
|
|
X ray tube
|
Focus:0.6/1.5mm;Anode heating capacity:76kHU
|
|
|
Digital detector
|
Limited resolution:3.6lp/mm; A/D conversion:14bit
|
|
|
Anatomy program
|
24 kinds of memory choices
|
|
|
Size
|
290×260×230 mm
|
|
|
Weight
|
18.8kg
|
|
|
Accessories
|
Standard: the switch, cables.7
|
|
